Heath Terminal Logic Board w/ Super19 ROM plus SigmaSoft Interactive Graphics Controller
Game Information
| manufacturer | ? |
| year | ? |
| genre | N/A |
| downloads | 0 |
Screenshots
Download Details
| split set | heath_igc_super19_tlb_device.zip 5.32k |
| bios/device | mm5740.zip 212.00b |
| merged set | heath_igc_super19_tlb_device.7z 4.67k |
| standalone set | heath_igc_super19_tlb_device.7z 4.74k |
Driver Details
| source | devices/bus/heathzenith/h19/tlb.cpp |
Screen Details
| display | :screen |
| type | raster |
| orientation | horizontal |
| width | 640px |
| height | 250px |
| refresh | 59.26mhz |
Input Details
| player | 1 |
| type | joy |
| buttons | 1 |
| directions | 8 |
| player | 1 |
| type | keyboard |
| buttons | 86 |
| directions | N/A |
| player | 2 |
| type | joy |
| buttons | 1 |
| directions | 8 |
Chipset Details
| name | Zilog Z80 |
| clock | 1.95mhz |
| name | Speaker |
| clock | N/A |
| name | Beep |
| clock | 0.98khz |
ROM Details
| name | size | crc |
|---|---|---|
| 2732_super19_h447.u437 | 4.00k | 6c51aaa6 |
| 2716_444-29_h19font.u420 | 2.00k | d595ac1d |
| 2716_444-37_h19keyb.u445 | 2.00k | 5c3e6972 |
