Heath Terminal Logic Board
Download Details
| split set | heath_tlb.zip 4.74KiB |
| merged set | heath_tlb.7z 3.93KiB |
| standalone set | heath_tlb.7z 4.01KiB |
| device | mm5740.zip 212.00B ↗ |
Driver Details
| source | devices/bus/heathzenith/h19/tlb.cpp |
| channels | 1 |
Screen Details
| display | :screen |
| type | raster |
| orientation | horizontal |
| width | 640 |
| height | 250 |
| refresh rate | 59.26hz |
Input Details
| player: | 1 |
| type | keyboard |
| directions | N/A |
| buttons | 86way |
Chipset Details
| Zilog Z80 | 2.05mhz |
| Speaker | present |
| Beep | 1.00khz |
ROM Details
| name | size | crc |
|---|---|---|
| 2732_444-46_h19code.u437 | 4.00KiB | f4447da0 |
| 2716_444-29_h19font.u420 | 2.00KiB | d595ac1d |
| 2716_444-37_h19keyb.u445 | 2.00KiB | 5c3e6972 |
