Sega Model 1 I/O Board (Advanced)
Download Details
| split set | model1io2.zip 16.66KiB |
| merged set | model1io2.7z 9.50KiB |
| standalone set | model1io2.7z 10.33KiB |
| device | hd44780.zip 965.00B ↗ |
Driver Details
| source | sega/model1io2.cpp |
Screen Details
| display | :screen |
| type | lcd |
| orientation | horizontal |
| width | 121 |
| height | 19 |
| refresh rate | 50.00hz |
Chipset Details
| type | cpu |
| tag | :iocpu |
| name | Toshiba TMPZ84C015 |
| clock | 9.83mhz |
ROM Details
| name | size | crc |
|---|---|---|
| epr-16891.6 | 64.00KiB | a33f84d1 |
| epr-18021.6 | 64.00KiB | 5551837e |
| epr-17181.6 | 64.00KiB | 1add2b82 |
